LAUNCH BST-560 Portable Battery System Tester
| Previous | 24 / 26 | Next |
LAUNCH BST-560
Portable Battery System Tester
6 Kind of Test
- Ripple Detection
- Electric Current Test
- Charging System Test
- Battery Test
- Starter Test
- Voltage Test
Product Features
- No necessary to remove the batery by detecting in the vehicle
- The battery test results are quick and accurate (within 3 Sec.)
- Bad-cell battery can be detected directly
- The status of charging voltage can be detected
- No heating, no discharge, no spark, no operating risks
- The starting voltage of the vehicle can be detected
- The USB port can export service records
- Test battery with loss of electricity (able to test low to 8V)
- Support Automatic temperature compensation function
- Available to the batch inspection of battery by testing continuously and repeatedly
- Support multiple languages menu
Test Range
| CCA | 100 ~ 2000 |
| DIN | 100 ~ 1400 |
| EN | 100 ~ 2000 |
| IEC | 100 ~ 2000 |
| SAE | 100 ~ 2000 |
| JIS | 26A17 ~ 245H52 |
| CA | 100 ~ 2000 |
| MCA | 100 ~ 2000 |
| BCI | 100 ~ 2000 |
| GB | 30Ah ~ 200Ah |
*Applicable battery types : 6V, 12V and 24V batteries
(Lead-acid battery, gel battery and AGM battery)
.jpg)
Technical Data
| Display | 4-line Graphic Lcd Display With Backlight |
| Test Cable | 80 mm Standard Cable |
| Working Temperature | -20 ~ 55°C |
| Dimension | 150*76*25mm |
| Weight | 300g |
| Case Material |
Abs Acid-proof Plastic, Industrial Case Design, Suitable for Repair workshops |
Language
European Configuration A : English, German, Italian, French, Polish, Russian
European Configuration B : Netherlands, Sweden, Finland, Turkey, Denmark, Norway
American Configuration : English, Spanish, Portuguese, French
Asia Configuration A : English, Traditional Chinese, Simplified Chinese
Asia Configuration B : English, Japanase, Korean
