DHC | BT900 12V/24V DC BATTERY ANALYZER TESTER

1. Testing Capabilities:

   • Battery Test: Supports 12V battery testing.
   • START-STOP Battery Test: Specifically designed to test Start/Stop batteries accurately.
   • Cranking/Charging System Test: Tests both 12V and 24V cranking and charging systems.
   • IR Test: Likely refers to internal resistance testing, which helps assess battery health.

2. Display and Interface:

   • LCD Screen: Features a 4-line LCD with adjustable brightness for easy viewing in various lighting conditions.

3. Printer:

   • Built-in Thermal Printer: Includes a 2” thermal printer that allows for quick and easy printing of test results.
   • Easy Load Design: Simplifies the process of replacing paper rolls in the printer.

4. Functionality:

   • In-Vehicle Test: Combines battery and system testing into a single operation, providing a comprehensive printed test result.
   • Temperature Compensation: Adjusts for temperature variations during testing (above/below 0ºC or 32ºF), ensuring accurate results.
   • Date & Time Function: Maintains date and time information with a built-in battery backup.
   • DIY Information: Allows customization of information on the printed receipt.
   • Print Last Result: Ability to reprint the last test result without retesting.
   • Backward Function Key: Enables correction of input errors by returning to the previous setting.

5. Design:

   • Slim & Lightweight: Designed for mobility, making it easier to carry and use in various environments.
   • Protective Boot: Provides added durability and protection against accidental damage.

Overall, the BT900 seems well-suited for professional mechanics or technicians needing a reliable tool for testing and diagnosing battery and electrical systems in vehicles. Its combination of testing capabilities, ease of use features like the built-in printer and adjustable LCD, and flexibility in handling different battery types (including Start/Stop) make it a valuable asset in automotive maintenance and repair scenarios.

Model Number: BT900

Application:

• 12V battery test
• 12V START-STOP battery test
• 12V & 24V cranking/charging system test
• IR test (Internal Resistance test)

LCD:

• 4-line LCD display with adjustable brightness

Printer:

• Built-in 2” thermal printer

Supported Battery Types:

• Flooded
• VRLA/GEL
• AGM Flat
• AGM Spiral
• EFB (Enhanced Flooded Battery)

Battery Ratings:

• CCA/SAE (Cold Cranking Amps)
• EN (European Norm)
• JIS (Japanese Industrial Standard)
• DIN (German Standard)
• IEC (International Electrotechnical Commission)
• CA/MCA (Cranking Amps/Marine Cranking Amps)

Operating Range:

• CCA (SAE): 40 to 2,000 CCA

Voltage Range:

• 8V to 31.5V

Dimensions (mm):

• 250 (Length) x 130 (Width) x 45 (Height)

Languages:

• English
• French
• Spanish
• German
• Italian
• Portuguese

These specifications outline the capabilities and technical details of the BT900, highlighting its versatility in testing various types of batteries and charging systems across different standards. The inclusion of multiple language options and a compact design with a built-in thermal printer enhances its utility and convenience for professional use in automotive maintenance and diagnostics.
